Precision alignment with less than 0.2mm deviation for flawless spot UV and foiling.
Pneumatic loading and belt-fed unloading streamline production and reduce manual effort.
Optional 2H setup boosts speed—prints A3 jobs in just 40 seconds.
Seamless transition from varnish to foil without traditional screen setups.
Handles coated paper, cardboard, lamination films, and SoftTouch materials from 135gsm to 400gsm.
Description
The V-JET 6040W is a compact, high-performance digital enhancement system built for post-press brilliance. Designed to elevate offset and digital prints, it features a CCD-assisted registration system that ensures pinpoint accuracy with less than 0.2mm deviation. Its automatic paper loading and unloading mechanisms—powered by pneumatic manipulators and belt feeders—enable continuous, hands-free operation.
With support for a wide range of substrates and thicknesses, the 6040W excels in producing premium greeting cards, catalogs, packaging, and promotional items. The drop-on-demand piezo printhead delivers crisp varnish effects, while its innovative foiling process eliminates the need for screens, making short-run jobs faster and more cost-effective.
Whether you’re enhancing print-on-demand materials or crafting personalized VIP vouchers, the V-JET 6040W combines speed, precision, and versatility to deliver stunning visual impact with every sheet.
Specifications
Model
VJET 6040W
Printhead
Drop-on-demand piezo, 1024 nozzles
Print Size
Min.210mm x 297mm | Max.600mm x 420mm
Printhead configuration
1H / 2H
Print Speed
1H
2H
It takes 55 seconds to print a job of standard A3 size
It takes 40 seconds to print a job of standard A3 size
Loading Capacity
To Hold 700 pcs (250 gsm)
Type
Coated paper, White cardboard, Matt lamination, SoftTouch Film.
Paper weight
135g/m²-400g/m²
UV curable varnish and capacity
Professional varnish printing, 2.5L
Registration
CCD Camera with difference less than 0.2mm
Printable area
Min.210mm x 297mm | Max.600mm x420mm
Printer
AC220V 50HZ 2750W
UV Lamp
AC220V 50HZ 300W
Operation Environment
Temperature: 20°C-28°C Humidity: 40%-60%
Printer Dimensions
L 2700mm x W 2200mm x H 1400mm
